Processor AMD Ryzen™ 7 260 (8C / 16T, 3.8 / 5.1GHz, 8MB L2 / 16MB L3)AI PC Category AI-Powered Gaming PCNPU Integrated AMD Ryzen™ AI, up to 16 TOPSGraphics NVIDIA® GeForce RTX™ 5060 8GB GDDR7, Boost Clock 2497MHz, TGP 115W, 572 AI TOPSChipset AMD SoC PlatformMemory 1x 16GB SO-DIMM DDR5-5600Memory Slots Two DDR5 SO-DIMM slots, dual-channel capableMax Memory Up to 32GB DDR5-5600 offeringStorage 1TB SSD M.2 2242 PCIe® 4.0x4 NVMe®Storage Slot Two M.2 2280 PCIe® 4.0 x4 slotsMax Storage Support Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB eachOptical NoneCard Reader NoneAudio Chip High Definition (HD) Audio, Realtek® ALC3287 codecSpeakers Stereo speakers, 2W x2, audio by HARMAN, optimized with Nahimic AudioMicrophone 2x, ArrayCamera 5.0MP with E-shutterBattery 80WhPower Adapter 245W Slim Tip (3-pin)Special Features AI Chip: LA1DESIGNDisplay 15.1" WQXGA (2560x1600) OLED 1000nits (peak) / 500nits (typical) glossy, 100% DCI-P3, 165Hz, Dolby Vision®, DisplayHDR™ True Black 600Touchscreen NoneScreen-to-Body Ratio OLED models: 90% AAR (active area ratio)Color Calibration Factory Color CalibrationPen Pen Not SupportedKeyboard 24-Zone RGB Backlit, EnglishTouchpad Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)Dimensions (WxDxH) 344.9 x 255.35 x 19.95-21.54 mm (13.58 x 10.05 x 0.79-0.85 inches)Weight Starting at 1.9 kg (4.19 lbs)Case Color Eclipse BlackCase Material Aluminium (Top), PC-ABS + 15% Talc (Bottom)Surface Treatment Aluminium Stamping (Anodized with Sandblasting)SOFTWAREOperating System NoneBundled Software NoneCONNECTIVITYWLAN + Bluetooth Wi-Fi® 7, 802.11be 2x2 + BT5.4WWAN Non-WWANEthernet 100/1000M (RJ-45)Standard Ports 2x USB-A (USB 5Gbps / USB 3.2 Gen 1)1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with USB PD 65-100W and DisplayPort™ 2.11x USB-C® (USB4® 40Gbps), with DP 1.41x HDMI® 2.1, up to 8K/60Hz1x Headphone / microphone combo jack (3.5mm)1x Ethernet (RJ-45)1x Power connectorDocking Various docking solutions supported via USB-C®.For more compatible docking solutions, please visit Docking for Legion 5 15AHP10SECURITY & PRIVACYSecurity Chip Firmware TPM 2.0 EnabledFingerprint Reader NoneOther Security E-shutterSERVICEBase Warranty 2-year, Courier or Carry-inIncluded Upgrade NoneACCESSORIESBundled Accessories NoneCERTIFICATIONSGreen Certifications ErP Lot 6/26RoHS compliantOther Certifications TÜV Rheinland® Flicker FreeTÜV Rheinland® Low Blue Light (Hardware Solution)MODEL INFORMATIONModel 83M0002FPBMachine Type 83M0Region EETCountry/Region PolandTopSeller NoEAN / UPC / JAN 198158681100Announce Date 2025-05-20End of Support 2031-06-16
Reference
00007182
Specific References
EAN13
198158681100
